Hydro Extracor
About the Products
- Outer Drum : Cylindrical Drum Mode Out of S.S
- Inner Drum : Revovling Perforated dmm made out of S.S. 304/316
- Volute : MS. Fabricated shell & Bottom
- Drive System : The machine is driven by 440V, 3ph TEFC Motor through Clutch pulley V belts
- Brake : Mechanical leg brake System
- Suspension : Cast iron tricolumn Suspensions with springs.
- Bearing Housing : Made out of graded cast iron machined for close tolerance to heavy duty bearings with proper lubrication.
- External Finish : Polished SS, Surfaces attractive colour ASPA Paint on M.S and C.I. Surfaces
Removes water by an effective extraction process quickly, resulting in very low Moisture retention
| Model | Inner Drum dia/ht | Drum R.P.M | Motor H.p | Capacity Kgs. (WET) |
|---|---|---|---|---|
| NHE - 25 | 630/350mm | 1000 | 3 | 25 kgs. |
| NHE -35 | 780/350mm | 1000 | 5 | 40 Kgs. |
| NHE -37 | 930/450 | 785 | 5/7.5 | 50 Kgs. |
| NHE -45 | 1030/50mm | 785 | 7.5 | 70 Kgs. |
| NHE -49 | 1230/50mm | 775 | 10 | 100 Kgs. |
