Tumbler Drier
About the Products
- Machine Body: Construction oi M.S. Channels. Square tubes and sheets with ~ prowsion for Electrical / Steam / LPG heating arrangements. Drive 3 assembly with auto - reversing. exhaust fan assembly Glass wool -, insulation. etc.
- Drum : Inner Drum mode out of S.S material with perforations tor penetration of hot air and "U" lifters for Proper tumble action, arrangements easily removable of drum.
- Drive: Driven by electric motor through pulley & V- Belt arrangements. easy belt tightening system. Electrical : Separate motors for drum and blower. Control panel with conductors. relays, fuses, digital timer, temperature controller, push button switches, buzzer to indicale process completion.
- Electrical : Separate motors for drum and blower. Control panel with conductors. relays, fuses, digital timer, temperature controller, push button switches, buzzer to indicale process completion.
- Safely : Inter lock limit switch for door and see through drive guard
- Finish : Outer body is painted with aspa heal - resistant paint/ SS outer panels are optional Energy, Time saving, Drying system, Drying, conditioning. Softening with Cost effective
| Model | Charging Capacity(Wet) | Motor H.P | Basket Dimenssion in Dia/Lt | Basket Speed | Driver Motor | Blower | Heater | Steam Consumption |
|---|---|---|---|---|---|---|---|---|
| NTD - 25 | 25 kgs | 1 | 730 / 530mm | 36 RPM | 1/2 HP | 1/2 HP | 12 KW | 20 Kgs |
| NTD -50 | 50 kgs | 2 | 930/900mm | 36 RPM | 1 HP | 1 HP | 18 KW | 35 Kgs |
| NMW -100 | 100 Kgs | 3 | 1230/950mm | 36 RPM | 2 HP | 1/2 HP | 24 KW | 65 Kgs |
