Washing Machines
About the Products
- Base Frame: The Skeleton Frame rigidly constructed with M.S. channels and plates
- Outer Drum : Outer Drum made out of S.S,, Bottom drain vaive, Thermometer, water and steam inlet nozzles Provided. It is having a top slider door. Soap hopper,electrical safety limit switch, etc.
- Inner Drum : The drum made out of S.S., with Proper embossed perforation S.S., 'U' Lifters are provided for proper reinforcement and to achieve tumbling of garments. The drum having spring lock arrangement for opening and closing of door
- Drive : Duplex chain drive through sprocket and pulley and easy arrangement for tightening V belts
- Electrical : AC Motor 1440 rpm, 440V 3ph control panel consists of forward reverse timer, Contractors, Over load Relay, Inter lock limit switch and buzzer to' indicate process completion External Finish S.S. Surfaces, Polished to mirror finish, attractive colourASPApainton M.S Surface
- Technical Service : Service years of online experience in dyeing and laundry equipment service. Customers can utilize our technical people best result.
Used for all types of washing like detergent, acid, caustic, sand, etc, with quick & effective processes
| Model | Charging Capacity(Wet) | Motor H.P | Rotating Drum Dia/Lt.mm |
Steam Connection Nozzle |
Drain Value Connection |
|---|---|---|---|---|---|
| NWM - 25 | 25 kgs | 1 | 730 / 995 | 25 NB | 1.5*P.P Valve |
| NMW -50 | 50 kgs | 2 | 830 / 1000 | 50 NB | 2.0*P.PValve |
| NMW -100 | 100 Kgs | 3 | 930 / 1250 | 50 NB | 3.0*P.PValve |
| NWM - 150 | 150 kgs | 5 | 1030 / 1400 | 50 NB | 3.0*P.PValve |
